Tensar® Glasstex Grid-R

2 Biaxial Grid, Strength in Two Directions
>0.9 Kg/M2 of Residual Bitumen Bond Coat Required
1 Primary Function of Reinforcement
  • One of a range of Tensar of asphalt interlayer products
  • Tensar has over 30 years of experience with asphalt interlayers
  • GlasstexGrid-R interlayer provides a reinforcement function to asphalt pavements
  • Controls cracking in asphalt to extend pavement life
Overview

GlasstexGrid-R is a low-profile interlayer product comprising a coated grid of glass filament bundles, bonded to a very lightweight non-woven backing fabric. The high-modulus glass filaments provide high absorption of stress at low strains, delivering a reinforcement function as defined by EN 15381. The polymer modified coating provides protection and stability to the glass yarn grid. The lightweight backing fabric is only present to assist with adhesion during installation and subsequently permits intimate contact between overlying asphalt and the underlying surface.

Product Range

Typically installed under the asphalt binder course, GlasstexGrid’s high-stiffness coated grid is bonded to the asphalt, providing a reinforcement function by absorbing stress at low strain levels.

The reinforced layer created, prolongs service life by controlling reflective cracking and mitigates longitudinal cracking caused by differential settlement between new and existing lanes on widened roads.

The Benefits of Tensar GlasstexGrid-R

One key benefit of GlasstexGrid-R is the way it controls reflective cracking in overlays. It also mitigates longitudinal cracking between new and existing lanes on widened roads.

How does Tensar GlasstexGrid-R control cracking?

The product is composed of a high-stiffness glass yarn grid. The open grid structure allows strikethrough and intimate contact between the asphalt layers above and below, and absorbs stress at low strains by bonding with the asphalt layers. The fabric component aids installation. The product provides a  reinforcement function, as defined in EN 15381.
