A brief history of Tensar geogrids

by Andrew Lees, on December 05, 2019

The 1970's marked a revolution in the construction of retaining structures and roads, with Tensar’s invention of polymeric geogrids.

A geogrid’s main function is to mechanically stabilise granular materials, reinforcing soil slopes and retaining walls; providing safe access over soft ground; reducing aggregate layer thickness in pavements and increasing the ground’s bearing capacity beneath roads and railways.

Tensar Ground Coffee Episode 4 - The Mercer Lecture

Who invented geogrids?

Geogrids were invented by Dr Brian Mercer, who patented the Netlon process of extruding molten plastic into grids, rather than weaving polymer fibres, in the 1950s. They proved popular in many industries, including civil engineering.

Brian-Mercer


Mercer saw the potential for wider use of geogrids in civil engineering, if he could make them stronger and more robust, and began developing a way of delivering these improvements.

His persistence paid off, with the invention of the revolutionary ‘Tensar process’ in 1978. This stretched the grid to align the polymer’s long chain molecules in the ribs and through the junctions, increasing strength and durability.

Tensar geogrid proves itself on first outing

Tensar geogrids were first trialled in 1980, to build a temporary retaining wall supporting a railway at Newmarket Silkstone Colliery, Yorkshire. Uniaxial geogrid was used to reinforce minestone waste, stabilising the embankments, while biaxial geogrid stabilised aggregate beneath.

Silkstone-colliery-tensar

Tensar geogrids were first trialled at Silkstone Colliery, Yorkshire, in 1980.

Performance exceeded all expectations, with no discernible settlement in three years, despite up to 300t of waste passing over the railway every hour. The fascination with what “a bit of plastic” could achieve even saw Tensar geogrids featured on the BBC’s Tomorrow’s World programme, which can be viewed here.

Continued success and evolution

Since then, Tensar geogrids have been used on thousands of projects globally to build earth retaining structures with up to 120 years design life and to support roads, railways and trafficked areas, saving significant time and money over alternative methods.


Tensar's next generation of geogrids Tensar InterAx was launched in 2021

Geogrids continue to evolve, with the best performing stabilisation geogrid, Tensar InterAx, launched in 2021. For roads, aggregate stabilised with Tensar InterAx delivers high performing pavements that are considerably thinner, last longer, use fewer materials and enable the reuse of low-quality site-won fill, drastically reducing environmental impact.

Our commitment to research and development

Our international reputation for innovation is built on our commitment to research and development over the past 35 years. We have invested significant sums of money in research projects around the world, with partners including the University of Nottingham, the University of Minnesota, Czech Technical University, Prague, the UK Transport Research Laboratory and the US Corps of Engineers.

US Corps

The US Corps of Engineers has carried out numerous full-scale performance trials of Tensar geogrids in road pavements.

Tensar geogrid: A revolutionary innovation

Mercer, awarded the Royal Academy of Engineering’s MacRobert Award for innovation in 1984, was convinced Tensar would be revolutionary. Nearly 20 years after his death, he has been proved right: in 2013 Tensar was named one of the British inventions of the 20th Century, alongside innovations including Alan Turing’s Universal Machine.

Mercer’s legacy is certainly here to stay. Geogrids will continue to make the “impossible, possible”, helping deliver infrastructure fit for the 21st Century and beyond.

Tensar geogrids: Wide ranging applications

Our innovative and high-performance geogrid and geotextile products offer alternative approaches to traditional methods. These have benefitted thousands of projects around the world, from road, rail and airport infrastructure to housing, commercial buildings, waste and landfill, and utilities and energy.

Fujirah Walls

Tensar’s TensarTech TW1 system was used to build up to 60m high reinforced soil retaining walls for the Fujairah Freeway connecting Dubai to Al Fujairah, UAE.

With an expert technical services team and an international network of distribution partners, we also provide professional support and impartial advice to projects, from product selection and engineering design, to on-site construction guidance.
